BASIC INFO
Double Braided Rope Features
Good anti-UV properties
Good antimicrobial performance
Acid resistance,alkali resistance and organic solvents
Good abrasion resistance
Application
Mainly used in ship mooring,towing,Marine fishing ,Marine aquaculture and other fields
| Size | Linear
Density ktex |
Standard
Tolerance % |
Weight | Min Breaking Strength | |||
| Diameter | Cir (inch) | KGS/220M | LBS/100FT | KN | Ton | ||
| 28 | 3-1/2 | 452 | ±5 | 99.4 | 30.4 | 168 | 17.1 |
| 32 | 4 | 535 | ±5 | 117.7 | 36.0 | 215 | 21.9 |
| 36 | 4-1/2 | 690 | ±5 | 151.8 | 46.4 | 258 | 26.3 |
| 40 | 5 | 877 | ±5 | 193.0 | 58.9 | 320 | 32.6 |
| 44 | 5-1/2 | 1086 | ±5 | 239.0 | 73.0 | 370 | 37.7 |
| 48 | 6 | 1300 | ±5 | 286.0 | 87.4 | 440 | 44.9 |
| 52 | 6-1/2 | 1496 | ±5 | 329.1 | 100.5 | 510 | 52.0 |
| 56 | 7 | 1773 | ±5 | 390.0 | 119.2 | 569 | 58.0 |
| 60 | 7-1/2 | 1995 | ±5 | 438.9 | 133.7 | 650 | 66.3 |
| 64 | 8 | 2223 | ±5 | 489.1 | 149.4 | 736 | 75.0 |
| 72 | 9 | 2836 | ±5 | 623.9 | 190.5 | 912 | 93.0 |
| 80 | 10 | 3477 | ±5 | 764.9 | 321.0 | 1110 | 113.0 |
| 88 | 11 | 4177 | ±5 | 919.0 | 280.7 | 1362 | 139.0 |
| 96 | 12 | 4940 | ±5 | 1086.8 | 332.0 | 1588 | 162.0 |
| 104 | 14 | 5810 | ±5 | 1278.2 | 390.5 | 1800 | 183.6 |
| 112 | 14 | 6723 | ±5 | 1479.0 | 452.0 | 2120 | 216.0 |
| 120 | 15 | 7740 | ±5 | 1703.0 | 520.4 | 2430 | 248.0 |
| 128 | 16 | 8682 | ±5 | 1910.0 | 583.5 | 2745 | 280.0 |
| 136 | 17 | 9680 | ±5 | 2129.0 | 650.7 | 3009 | 307.0 |
| 144 | 18 | 10680 | ±5 | 2350.0 | 717.7 | 3248 | 331.0 |
