BASIC INFO
Polyester Rope Features：
Good thermostability
Stable wear-resisting performance
Anti-aging,UV resistance. Anti-fungus
Stable chemical performance, acid resistance
Stretch resistance, good rigidity, not easy deformation
Good wear resistance, high intensity, long service life
Good UV protection performance(UPF)
Application:
It is mainly used for mooring ships, ocean transportation, port terminals,national defense .mine traction,etc.
| Size | Linear Density ktex |
Standard Tolerance % |
Weight | Min Breaking Strength |
|||
| Diameter | Cir(inch) | KGS/220M | LBS/100FT | KN | Ton | ||
| 28 | 3-1/2 | 594 | ±5 | 130.7 | 39.9 | 132 | 13.5 |
| 32 | 4 | 778 | ±5 | 171.2 | 52.3 | 169 | 17.2 |
| 36 | 4-1/2 | 982 | ±5 | 216.0 | 66.0 | 209 | 21.3 |
| 40 | 5 | 1215 | ±5 | 267.3 | 81.7 | 258 | 26.3 |
| 44 | 5-1/2 | 1468 | ±5 | 323.0 | 98.7 | 307 | 31.3 |
| 48 | 6 | 1750 | ±5 | 385.0 | 117.6 | 362 | 36.9 |
| 52 | 6-1/2 | 2050 | ±5 | 451.0 | 137.8 | 422 | 43.0 |
| 56 | 7 | 2380 | ±5 | 523.6 | 160.0 | 483 | 49.3 |
| 60 | 7-1/2 | 2730 | ±5 | 600.6 | 183.5 | 538 | 54.9 |
| 64 | 8 | 3110 | ±5 | 684.2 | 209.0 | 625 | 63.8 |
| 72 | 9 | 3930 | ±5 | 864.6 | 264.1 | 777 | 79.3 |
| 80 | 10 | 4850 | ±5 | 1067.0 | 326.0 | 954 | 97.3 |
| 88 | 11 | 5870 | ±5 | 1291.4 | 395.0 | 1144 | 116.7 |
| 96 | 12 | 6990 | ±5 | 1537.8 | 470.0 | 1353 | 138.0 |
| 104 | 14 | 8200 | ±5 | 1804.0 | 551.0 | 1562 | 159.3 |
| 112 | 14 | 9500 | ±5 | 2090.0 | 638.5 | 1782 | 181.8 |
| 120 | 15 | 10900 | ±5 | 2398.0 | 723.5 | 2052 | 209.3 |
| 128 | 16 | 12400 | ±5 | 2728.0 | 833.3 | 2321 | 236.7 |
| 136 | 17 | 14000 | ±5 | 3080.0 | 941.0 | 2640 | 269.3 |
| 144 | 18 | 15700 | ±5 | 3454.0 | 1055.0 | 2915 | 297.3 |
| 152 | 19 | 17550 | ±5 | 3861.0 | 1179.4 | 3256 | 332.0 |
| 160 | 20 | 19400 | ±5 | 4268.0 | 1304.0 | 3597 | 367.0 |
