BASIC INFO
Polyamide Multifilament Rope Features:
Alkali resistance
High resilience
Best wear-resisting performance
Best UV protection performance
Application :
Widely used in large ships, warships, towing, oil exploration, fisheries, mining and many other fields.
| Size | Linear Desity ktex |
Standard Tolerance % |
Weight | Min Breaking Strength |
|||
| Diameter | Cir(inch) | KGS/220M | LBS/100FT | KN | Ton | ||
| 28 | 3-1/2 | 485 | ±5 | 106.7 | 32.6 | 177 | 18.0 |
| 32 | 4 | 630 | ±5 | 138.6 | 42.3 | 228 | 23.26 |
| 36 | 4-1/2 | 800 | ±5 | 176.0 | 53.8 | 287 | 29.27 |
| 40 | 5 | 990 | ±5 | 217.8 | 66.5 | 348 | 35.45 |
| 44 | 5-1/2 | 1200 | ±5 | 264.0 | 80.6 | 415 | 42.33 |
| 48 | 6 | 1420 | ±5 | 312.4 | 95.4 | 476 | 48.60 |
| 52 | 6-1/2 | 1660 | ±5 | 365.2 | 111.6 | 558 | 56.92 |
| 56 | 7 | 1930 | ±5 | 424.6 | 130.0 | 630 | 64.26 |
| 60 | 7-1/2 | 2210 | ±5 | 486.2 | 148.5 | 710 | 72.42 |
| 64 | 8 | 2520 | ±5 | 554.4 | 169.4 | 813 | 82.93 |
| 72 | 9 | 3190 | ±5 | 701.8 | 214.4 | 1005 | 102.51 |
| 80 | 10 | 3940 | ±5 | 866.8 | 265.0 | 1230 | 125.46 |
| 88 | 11 | 4770 | ±5 | 1049.4 | 321.0 | 1455 | 148.40 |
| 96 | 12 | 5680 | ±5 | 1249.6 | 380.0 | 1702 | 193.60 |
| 104 | 14 | 6660 | ±5 | 1463.2 | 444.0 | 2020 | 206.00 |
| 112 | 14 | 7720 | ±5 | 1698.4 | 519.0 | 2215 | 225.93 |
| 120 | 15 | 8870 | ±5 | 1951.4 | 596.1 | 2535 | 258.57 |
| 128 | 16 | 10100 | ±5 | 2222.0 | 679.0 | 2915 | 297.33 |
| 136 | 17 | 11400 | ±5 | 2508.0 | 766.1 | 3185 | 324.87 |
| 144 | 18 | 12800 | ±5 | 2816.0 | 860.2 | 3575 | 364.65 |
| 152 | 19 | 14300 | ±5 | 3146.0 | 961.0 | 3925 | 400.35 |
| 160 | 20 | 15800 | ±5 | 3476.0 | 1062.0 | 4295 | 438.00 |
