BASIC INFO
Polyethylene Tow Rope Feature
High intensity
Chemical resistance,
Wear resistance
Fatigue resistance and flexible.
Anti-water,moisture resistance and anti-vibration
Application
Widely used in cable traction, hoisting rigging, wind and power industry, mining ,ocean petroleum
and military engineering
|
Core diameter （mm） |
Including cover diameter
（mm） |
Linear density
ktex |
Minimum breaking fore Kn ton |
|
| 6 | 9 | 32 | 36 | 3.57 |
| 7 | 10 | 42 | 50 | 5.10 |
| 8 | 12 | 55 | 60 | 6.12 |
| 9 | 13 | 65 | 75 | 7.65 |
| 10 | 14 | 75 | 98 | 10.0 |
| 11 | 15 | 100 | 115 | 11.73 |
| 12 | 16 | 117 | 135 | 13.77 |
| 13 | 17 | 130 | 160 | 16.32 |
| 14 | 18 | 165 | 190 | 19.38 |
| 15 | 19 | 188 | 210 | 21.42 |
| 16 | 20 | 213 | 240 | 24.48 |
| 17 | 21 | 235 | 271 | 27.64 |
| 18 | 22 | 265 | 296 | 30.20 |
| 19 | 24 | 287 | 328 | 33.50 |
| 22 | 26 | 395 | 425 | 43.35 |
| 24 | 28 | 463 | 495 | 50.49 |
